Product details
Package Dimensions ‏ : ‎ 1.85 x 1.77 x 0.67 inches; 2.59 Ounces
Item model number ‏ : ‎ NJ 203 ECP
Date First Available ‏ : ‎ January 15, 2019
Manufacturer ‏ : ‎ SKF
ASIN ‏ : ‎ B07FMTL8PJ
Product Description
Specification:

Item: Cylindrical Roller Bearing
Type: Open
Bore Dia.: 17mm
Tolerance: +0/-.008mm
Outside Dia.: 40
Outside Dia. Tolerance: +0/-.011mm
Width: 12
Fillet Radii (In.): 0.0236
Fillet Radii (mm): 0.6
Outer Ring Inside Dia. (In.): 1.2756
Outer Ring Inside Dia. (mm): 32.4
Inner Ring Outside Dia. (In.): 0.984
Inner Ring Outside Dia. (mm): 25
Shoulder Height (In.): 1.4016
Shoulder Height (mm): 35.6
Dynamic Load Capacity (Lb.): 3900
Static Load Capacity (Lb.): 3200
Temp. Range (F): -40 Degrees to 205 Degrees
Cage Material: Polyamide
Roller Material: Steel

<>SKF NJ 203 ECP bearing Cylindrical Roller Bearing,Bore 17mm
