FAG 6203ZR Deep Groove Ball Bearing, Single Row, ABEC 1 Precision, Single Shield, Steel Cage, Normal Clearance, Metric, 17mm ID, 40mm OD, 12mm Width, 18000rpm Maximum Rotational Speed, 1060lbf Static Load Capacity, 2160lbf Dynamic Load Capacity



Specifications for this item
Bearing Type Ball Bearing
Bore Diameter 17 millimeters
Brand Name FAG Bearings
Compatible Lubricant Type Grease
Dynamic Load Capacity 2160 pounds

Item Diameter 40 millimeters
Material Alloy Steel
Maximum Rotational Speed 18000 rpm
Measurement System Metric
Number of Items 1
Part Number 6203-Z
Specification Met Din 623-1 , Iso 281 , Iso 683-17 , Iso 199 , Din Iso 281 , En 10139 , Sae J403
Static Load Capacity 1060 pounds
UNSPSC Code 31171500
Width 12 millimeters

<>$4 FAG 6203ZR Deep Groove Ball Bearing
